Description

• 【Outstanding industrial design】CNC machined aluminum extrusion and semi-assembled parts for reliable build quality and easy setup. V-guide roller made of Germany POM material with ultra-silence, accurate motion, and excellent wear resistance during long-term printing. 220X220X250mm printing size at ±0.1mm high precision. Supports multi-function extensions as well.
• 【Smarter 3D printing】Once a print is complete and the nozzle temperature drops below 50° Celsius, the cooling fans of the nozzle and the motherboard will automatically stop working, saving power and extending their lifespan. Resume printing from where it left after an unexpected power outage or faulty operations. MK8 extruder has wide material compatibility and equipped filament detection sensor will pause printing when filament runs out.
• 【Safe and stable power supply】400Watt switched-mode power supply can better protect your printing from short circuit, overload voltage, or under-voltage situations. The 250Watt hotbed can be heated to 100° Celsius within 3 minutes under an average indoor temperature and keeps it stable to meet different filament materials' working requirements.
• 【Intuitive and user-friendly experience】Multi-language user interface show the model preview and real-time printing progress. Large rotary nuts make leveling easier. The hotbed holds a replaceable fiberglass sheet with a matte Polycarbonate surface, which has a stronger adhesion and allows you to remove models without any hassle. 32bit motherboard with TMC2225 silent driver provides a quieter printing at 50db noise level and ensures consistent printing for 200 hours without any issues.
• 【Warranty and Service】We provide a 1-year warranty on the printer (nozzle and build plate sheet excluded) and lifetime technical support with fast response in customer service. If you need a replacement part, we will deliver it to you from the local warehouses giving you a better after-sales experience.

Description

Description

【Overview of Neptune 3 Pro】225*225*280mm market mainstream printing size can meet the needs of most users.
With an STM32 motherboard, all axes of ELEGOO Neptune 3 Pro are driven by silent stepper motors for quieter and more precise movement during printing, which reduces the noise as low as 47-48dB.
The easy-to-setup printer comes with the main components pre-assembled, as well as a complete tool kit for quick installation.

【Dual-Gear Direct Extruder】The new dual-gear direct drive extruder is made of SUS303 high-quality stainless steel with a 3:1 reduction ratio and stronger extrusion force for smoother filament feeding and more stable & accurate printing, which greatly reduces nozzle clogging and under-extrusion issues, printing effect is better than Bowden extruder. Compatible with multiple filaments such as PLA, TPU, PETG, and ABS.

【Nozzle Kit for Better Printing Effect】The nozzle kit contains a TC4 titanium alloy throat pipe, an aluminum alloy flat heat sink structure, and a brass nozzle.
The widened aluminum heat sink paired with the front close-fitting efficient cooling fan for a better heat dissipation effect and lower the temperature of the throat pipe, thereby reducing the possibility of nozzle clogging.
Fans on both sides of the print head ensure omnidirectional and rapid cooling of printed layers to improve the model details and overhang printing effect.

【Smarter Printing Experience】Auto mesh bed leveling adopts a non-contact high precision sensor to automatically scan 36 (6x6) points of the hotbed and collect data in real-time, and then adjust the Z-axis height to compensate for any irregularities and unevenness of the printing platform. (Only applicable to metal printing platforms)
Intelligent fan control: after printing, all fans will automatically stop working below 50℃ to extend fan lifespan, reduce noise, and save power.
Smart resume printing: the printer will auto-pause when the filament runs out or breaks, and you can resume printing after a power outage.

【More Stable Printing】The Z-axis with dual synchronized lead screws and dual-motor drive for more stable movement of the print head and higher printing accuracy, avoiding the printing deviation driven by a single Z-axis lead screw motor.
The 4-wheel V-guide rail pulley is made of POM with more stable movement, low noise, wear resistance, and longer service life.

【Ease of Use】PEI magnetic platform with a special coating and spring steel sheet for good adhesion and anti-warping, so that prints can be easily released or popped off by bending the print steel sheet.
The 4.3-inch removable capacitive touch screen can be operated by hand-held or fixed on the base. Built-in print model preview function to preview the model image before printing and observe the printing progress.
The 250W high-power hotbed can quickly heat up to 100ºC and start printing.
The integrated LED light bar on the gantry can be operated by pressing the buttons on the screen to conveniently observe the model printing in a poor light environment.

Description

• 【Faster printing speed】Saturn 3D printer comes with an 8.9inch 4K Monochrome LCD with an HD resolution of 3840 x 2400, reducing the layer printing time to 1.5s-2s, which is 60% faster than Mars Pro yet still delivers outstanding printing results.
• 【Larger build volume】Saturn has a large printing volume of 192*120*200mm/7.55in*4.72in*7.87in, and you can print multiple full-sized models at the same time, which can dramatically improve your productivity.
• 【Higher precision and easier printing】Z-axis utilizes a double linear guideway structure, which can achieve steadier motion and greatly enhanced moving accuracy. With the ethernet port on the back and a 4GB built-in data disk, Saturn now supports file transfer through your local area network, which is very handy for fast printing.
• 【Quality Prints and Consistent Success】Matrix light source consists of 54 UV LED lights with uniform light emission, ensuring superior print results and more accurate printing size. The set screws on the build plate assure long-lasting leveling, no need for frequent calibration, and the sandblasted surface provides a much stronger adherence, especially when printing large 3D models.
• We provide a 1-year warranty on the whole printer (4K LCD, FEP film, and tool kit excluded). Replacement parts will be shipped from the overseas warehouse to offer you quality and fast customer service.

Learn more about ELEGOO Saturn:

Parameters and Specification:

System: EL3D-3.0.1
Operation: 3.5 Inch Touch Screen
Slicer Software: Chitubox
Connectivity: USB
Technology: LCD UV Photocuring
Lightsource: UV Integrated LED lights (wavelength 405nm)
XY Resolution: 0.05mm(3840×2400)
Z Axis Accuracy: 0.00125mm
Layer Thickness: 0.01-0.15mm
Printing Speed: 30mm/h
Power Requirements: 100-220V 24V4A 96W
Printer Dimensions: 11.02in (L) * 9.44in (W) * 17.55in (H) 28cm(L) * 24cm (W) * 44.6cm (H)
Build Volume: 7.55in (L) * 4.72in (W) * 7.87in (H) 192mm (L) * 120mm (W) * 200mm (H)
Weight: 29.76 Lbs (13.5 Kg)

Finish Kit includes:

Saturn 3D Printer * 1
Build Platform * 1
Resin Tank * 1
U Disk * 1
Mask * 2
Gloves * 3
Metal Scraper * 1
Plastic Scraper * 1
User Instruction * 1
Funnel * 10
Measuring Cup * 1
Backup Screws * 1
Adapter 120W * 1
Tool Kit*1
Leveling Paper*1
Myminifactory 10% OFF Discount Card*1

Description

[Faster printing speed] Saturn 3D printer comes with an 8.9inch 4K Monochrome LCD with an HD resolution of 3840 x 2400, reducing the layer printing time to 1.5s-2s, which is 60% faster than Mars Pro yet still delivers outstanding printing results.

[Larger build volume] Saturn has a large printing volume of 192*120*200mm/7.55in*4.72in*7.87in, and you can print multiple full-sized models at the same time, which can dramatically improve your productivity.

[Higher precision and easier printing] Z-axis utilizes a double linear guideway structure, which can achieve steadier motion and greatly enhanced moving accuracy. With the ethernet port on the back and 4GB built-in data disk, Saturn now supports file transfer through your local area network, which is very handy for fast printing.

[Quality Prints and Consistent Success] Matrix light source consists of 54 UV LED lights with uniform light emission, ensuring superior print results and a more accurate printing size. The set screws on the build plate assure longlasting leveling, no need for frequent calibration, and the sandblasted surface provides a much stronger adherence, especially when printing large 3D models.

Description

• 【Fast Slicing Software】ELEGOO Mars comes with the latest version of CHITUBOX Slicing Software which gives you an extraordinary user experience. CHITUBOX takes only 1 minute to slice 30Mb .stl model files while the open-sourced slicing software would take up to 10minutes.
• 【Resin saving and Better Printing】CHITUBOX allows you to hollow out your model before slicing which could save your resin dramatically during the photocuring process. Equipped with 40W UV lights and using ELEGOO resin, you can get a better printing result.
• 【Smart and Convenient】3.5'' inch color touch screen equipped with the latest ELEGOO CHITUBOX 5.5 system makes it very easy for off-line printing. The build platform with steel ball balancing structure inside allows you to start printing within 5 minutes after assembly.
• 【High Precision and Resolution】ELEGOO Mars uses a 2560x1440 2K HD masking LCD to provide accurate printing with XY axis resolution of 0.00185inches / 0.047mm
• 【Warranty and Service】We provide a total one-year machine warranty (3-month warranty for FEP and 2K LCD consumable parts) and if you have any questions regarding product operation or software please feel free to contact us

ELEGOO has been manufacturing 3D printer components and parts since 2014 and with years of experience in 3D printing, we finally developed our own 3D printer using UV photocuring technology. We'd like to present to you our very first photocuring LCD 3D Printer- ELEGOO Mars.

Great industrial design and user-friendly system, we make ELEGOO Mars suitable for anyone to use even though you have never used a 3D printer before.

The semi-assembled printer will save your time setting up when you receive it and within 5 minutes you could start printing your first model we provided – 2 rooks, which could be easily sliced using our newly released CHITUBOX slicing software.

Description

Pre-owned Machines

• 【Higher Precision and Excellent Performance 】Z-axis utilize linear guideway structure, which can achieve steadier motion and greatly enhanced moving accuracy to reduce the layer lines on the 3D printed model and make the surface much smoother. The set screws of the build plate are now upgraded to larger anti-slip hexagon socket screws, which have a more stable leveling result. CNC turning CD pattern on the build plate provides a much stronger adherence, especially when printing large 3D models.
• 【 Refreshing and Safer Experience】Mars Pro comes with a silicone rubber seal that can be put on the cover to prevent the resin odor from leaking and keep them inside the cover. Built-in activated carbon can absorb and filter the resin odor before they are ventilated throughout the cooling fan, which gives you a refreshing and safer user experience
• 【Light and Convenient 】Remodeled resin vat made of aluminum alloy is light yet sturdy. The USB port is relocated to the front for your convenience. Mars Pro uses a new user interface with a dark theme and a simple design.
• 【Quality Prints and Consistent Success】Matrix light source consists of 28 50Watt UV LED lights that have uniform light emission, ensuring superior printing results, a more accurate printing size, and saves your time by 25% in layer exposure time. Mars Pro is the first resin-based 3D printer to use the sliced file of .ctb format, which reduces the file size by an average of 90% compared to .cbddlp format and significantly increased the printing success rate when printing bigger models.
• 【Warranty and Privilege 】We provide a 1-year warranty on the whole printer and a 6-month warranty for the 2K LCD (FEP film is excluded). Parts and replacements will be shipped from the overseas warehouse to offer you quality and fast customer service. Mars Pro also comes with a Myminifactory Membership Card, which gives you the privilege to millions of curated 3D objects to start your first printing on Mars Pro.

Ever since ELEGOO Mars launched from the first day, we have received a lot of compliments as well as critical reviews. What can we improve from ELEGOO Mars to make it more perfect and easy to use?

To learn from the great ideas and give back to the community, we now proudly present you the MARS PRO.

Description

• 【Fast Printing and less maintenance】Mars 2 comes with a 6.08-inch monochrome LCD of 2K HD resolution and only takes 2 seconds per layer exposure to cure resin, which could significantly enhance your printing efficiency. Mono LCD has a much longer lifespan and stable performance during long-term printing thus saves your cost.
• 【Outstanding prints and ultra accurcy】Brand new light source structure provides more even UV light emission and working together with 2K mono LCD, the printing details and precision are greatly improved and the 3D printed models are fascinating.
• 【Sturdy build quality】CNC machined aluminum body makes Mars 2 a very formidable machine. Newly-designed sandblasted build plate has a much stronger adherence during printing and enables consistent printing success.
• 【Multi language interface】Mars 2 now supports 12 kinds of languages so customers across the world could operate the 3D printer more conveniently without barriers. The newly added 10 languages are Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, and Portuguese.
• 【Warranty and Service】We provide a 1-year warranty on the whole printer and a 6-month warranty for the 2K LCD (FEP film is excluded) .

Technical Specifications: System: EL3D-3.0.2Slicer Software: ChituBox Technology: UV Photocuring Layer Thickness: 0.01-0.2mm Printing Speed: 30-50mm/h Z Axis Accuracy: 0.00125mm XY Resolution: 0.05mm(1620*2560) Build Volume: 129mm(L)*80mm(W)*150mm(H) Light Source: UV Integrated Light (wavelength 405nm) Connectivity: USB Weight: 13.67lbs(6.2kg) Operation: 3.5 Inch Touch Screen Power Requirements: 100-240V 50/60Hz Printer Dimensions: 20cm (L)*20cm (W)*41cm (H)

2K Monochrome LCD ELEGOO Mars 2 MSLA 3D Printer comes with a 6.08-inch Monochrome LCD that has 2K HD resolution. It is four times longer in lifespan and two times faster in printing speed than the regular RGB LCD 3D printers, which means higher printing efficiency, more stable performance, and less maintenance.	Multi-language Interface The new operating system now supports 13 different languages: Chinese, English, Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, and Portuguese, which significantly facilitates worldwide users to use Mars 2 more conveniently.	Replaceable Resin Tank With a green Plastic Tank, it adopts special engineering plastics, environmental protection and can be degraded. According to your needs, you can replace your printer tank to extend the life of your printer.
CNC Machined Aluminum Mars 2 is made of CNC machined aluminum, it has a very solid build quality and high durability like a reliable workhorse that always get its work done.	COB UV LED Light Source Excellent heat dissipation performance, high luminous maintenance rate, uniform light emission, and no spots. COB light source has proved itself to be a fantastic upgrade that ensures each printing comes out perfectly.	Chitu Box Slicer ChituBox has been a very helpful companion when you are using ELEGOO MSLA resin 3D printers from slicing .stl file to adding supports. With the latest 8-times anti-aliasing function, you can get a much smoother printing surface.
